LASER SOLDERING

WITH THE J-CAT STAR GATE LASER SOLDERING ROBOT

J-CAT STAR GATE

This robot is non-contact soldering; it heats up the target with a high energy light emitted from an oscillated laser diode and is focused with a lens.  It is an 80Watt laser with an infrared wavelength of 925nm. The Stargate has has an infrared pyrometer option that provides real-time temperature control.

---

How Laser Soldering Works And Why You Should Be Interested

Laser soldering is a non-contact process that eliminates the risk of marring or damaging sensitive components.  Robots are capable of producing micro-sized laser beams for otherwise difficult applications too small for iron tip soldering.  Our advanced optical technology provides a reliable solution for micro and narrow pitched parts used in high-density electronic equipment.

The laser soldering process depends on the type of solder to be used (wire, pre-form or paste). In the case of solder wire, laser irradiation is performed in advance to the joint area (pre-heating). This is the most important process in order to wet and allow the solder to flow easily when supplying the solder wire to the joint area.

---

Related Technologies

Dispensing

Solder Paste Dispensers

Achieve ultimate small volume stability with precision nozzles.  Dispensing technology provides an alternative to the classic wire feed approach.  Dispensers allow for a precise amount of solder paste to be evenly distributed in micro amounts.  This approach eliminates waste and increases cost effectiveness.

---

Laser Lenses

Lenses

The type of lens to form a laser beam is composed of two components, the “Input lens” and “Output lens”. With the combination of these lenses, over 100 diameter variations can be achieved.
